PART # KIT61014
Features included in this kit:
- 4mm chassis with pockets cutout for weight reduction
- 3 mm front shock tower
- 3 mm rear shock tower
- 2 adjustable front body mounts with carbon fiber printed holder and clip style body post
- 2 adjustable rear body mounts with carbon fiber printed holder and clip style body post
- 3mm cf transmission riser plate with a 9mm carbon fiber printed riser plate. This keeps the axles level, helps lower the center of gravity, and is also the lower wheelie bar mount
- 2.5mm carbon fiber rear body mount
- Wheelie bar with adjustable support rod mounting locations and dragger plate.
- Onyx 3d printed wheelie bar support rod mount
- 4mm lcg motor plate that allows for large spur gear and small pinion and can withstand the torque of the high powered motors
- Centered steering servo under the front shock tower to allow you to move your battery forward for better weight distribution with servo saver
- 2.5mm carbon fiber adjustable front bumper with a place to install the associated servo weight plate
- 2.5mm carbon fiber adjustable mid bumper that mounts between the chassis and front bumper
- 3D printed chassis protector/skid plate that mounts on the underside between the mid bumper and the chassis.
- Aluminum 15* caster blocks and made to fit the TLR front arms
- New turnbuckles for steering
- All hardware needed that is not included in the TLR kit
****PARTS NOT INCLUDED BUT NEEDED TO COMPLETE THE KIT****
- TLR 22 5.0 Kit
- Electronics such as the ESC, motor, receiver, battery
- Wheels and tires
- Body
